Smart Serisi
Smart Exclusive
Mikroişlemcili kontrol panoları, tek faz veya trifaz olarak 4 pompaya kadar sistemi kontrol eder. Smart Exclusive, sisteminizi yönetmeyi, parametreleri değiştirmeyi, olayları ve mesajları kayıt altına alma gibi işlemleri pratik bir şekilde yapmanızı sağlar. Atık su ve temiz su uygulamaları için basınçlandırma, boşaltma, doldurma işlemlerinde kullanılır.
ÖZELLİKLER
- 3G / Wi-Fi modül sayesinde uzaktan sistemi işletme, verileri görüntüleme ve kontrol etme
- LCD ekran üzerinden kolay ve hızlı ayar
- Şamandıra, basınç sensörü/anahtarı veya seviye elektrodundan gelen bilgilerle sistemi yönetir
TEKNİK ÖZELLİKLER
Metal / IP 54 / Su Geçirmez | Kilitleme mekanizmalı ana kesici
Güç: 1~230V veya 3~400V ±%15, 50/60Hz | Motor/Hata LED
Motor aşırı akım, faz kaybı ve kuru çalışma koruması | Motor koruma sigortaları
Uygulama
Exclusive D (3 Pompa)
| KOD | V- | kW | Hp | Aralık (A) | Max (A) | D | E | G | Malzeme | KG | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Exclusive D 3 / Mono | 1071 | 1 - 230 | 2.2 | 3 | 0-18 | 18 | 600 | 400 | 200 | Metal | — |
| Exclusive D 3 - 4/ Tri | 15001 | 3 - 400 | 4 | 5.5 | 0-8.6 | 0-8.6 | 600 | 400 | 200 | Metal | — |
| Exclusive D 3 - 5.5 / Tri | 15002 | 3 - 400 | 5.5 | 7.5 | 0-11.6 | 0-11.6 | 600 | 400 | 200 | Metal | — |
| Exclusive D 3 - 7.5 / Tri | 15003 | 3 - 400 | 7.5 | 10 | 0-15.8 | 0-15.8 | 600 | 400 | 200 | Metal | — |
| Exclusive D 3 - 11 / Tri | 15004 | 3 - 400 | 11 | 15 | 0-25 | 25 | 600 | 400 | 200 | Metal | — |
| Exclusive D 3 - 15 / Tri | 15005 | 3 - 400 | 15 | 20 | 0-32 | 32 | 600 | 400 | 200 | Metal | — |
Exclusive D (4 Pompa)
| KOD | V- | kW | Hp | Aralık (A) | Max (A) | D | E | G | Malzeme | KG | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Exclusive D 4 / Mono | 1081 | 1 - 230 | 2.2 | 3 | 0-18 | 18 | 600 | 400 | 200 | Metal | — |
| Exclusive D 4 - 4/ Tri | 15201 | 3 - 400 | 4 | 5.5 | 0-8.6 | 0-8.6 | 600 | 400 | 200 | Metal | — |
| Exclusive D 4 - 5.5 / Tri | 15202 | 3 - 400 | 5.5 | 7.5 | 0-11.6 | 0-11.6 | 600 | 400 | 200 | Metal | — |
| Exclusive D 4 - 7.5 / Tri | 15203 | 3 - 400 | 7.5 | 10 | 0-15.8 | 0-15.8 | 600 | 400 | 200 | Metal | — |
| Exclusive D 4 - 11 / Tri | 15204 | 3 - 400 | 11 | 15 | 0-25 | 25 | 600 | 400 | 200 | Metal | — |
| Exclusive D 4 - 15 / Tri | 15205 | 3 - 400 | 15 | 20 | 0-32 | 32 | 600 | 400 | 200 | Metal | — |
Exclusive S 1
| KOD | V- | kW | Hp | Aralık (A) | Max (A) | D | E | G | Malzeme | KG | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Exclusive S 1 - 7.5 / Tri | 16001 | 3 - 400 | 7.5 | 10 | 0-15.8 | 15.8 | 400 | 300 | 175 | ABS | — |
| Exclusive S 1 - 11 / Tri | 16002 | 3 - 400 | 11 | 15 | 0-25 | 25 | 400 | 300 | 175 | ABS | — |
| Exclusive S 1 - 15 / Tri | 16003 | 3 - 400 | 15 | 20 | 0-31.9 | 31.9 | 600 | 400 | 200 | Metal | — |
| Exclusive S 1 - 18.5 / Tri | 16004 | 3 - 400 | 18.5 | 25 | 0-37.1 | 37.1 | 600 | 400 | 200 | Metal | — |
| Exclusive S 1 - 22 / Tri | 16005 | 3 - 400 | 22 | 30 | 0-42.7 | 42.7 | 600 | 400 | 200 | Metal | — |
| Exclusive S 1 - 30 / Tri | 16006 | 3 - 400 | 30 | 40 | 0-57.6 | 57.6 | 600 | 400 | 200 | Metal | — |
| Exclusive S 1 - 37 / Tri | 16007 | 3 - 400 | 37 | 50 | 0-70.2 | 70.2 | 600 | 400 | 200 | Metal | — |
| Exclusive S 1 - 45 / Tri | 16008 | 3 - 400 | 45 | 60 | 0-83.5 | 83.5 | 700 | 500 | 200 | Metal | — |
| Exclusive S 1 - 55 / Tri | 16009 | 3 - 400 | 55 | 75 | 0-100.9 | 100.9 | 700 | 500 | 200 | Metal | — |
| Exclusive S 1 - 75 / Tri | 16010 | 3 - 400 | 75 | 100 | 0-140.7 | 140.7 | 700 | 500 | 200 | Metal | — |
| Exclusive S 1 - 90 / Tri | 16011 | 3 - 400 | 90 | 125 | 0-165.1 | 165.1 | 800 | 600 | 290 | Metal | — |
| Exclusive S 1 - 110 / Tri | 16012 | 3 - 400 | 110 | 150 | 0-201.9 | 201.9 | 800 | 600 | 290 | Metal | — |
| Exclusive S 1 - 132 / Tri | 16013 | 3 - 400 | 132 | 180 | 0-242.2 | 242.2 | 1000 | 700 | 320 | Metal | — |
| Exclusive S 1 - 160 / Tri | 16014 | 3 - 400 | 160 | 220 | 0-290.6 | 290.6 | 1000 | 700 | 320 | Metal | — |
| Exclusive S 1 - 185 / Tri | 16015 | 3 - 400 | 185 | 250 | 0-332.4 | 332.4 | 1200 | 800 | 340 | Metal | — |
| Exclusive S 1 - 200 / Tri | 16016 | 3 - 400 | 200 | 270 | 0-355.4 | 355.4 | 1200 | 800 | 340 | Metal | — |
| Exclusive S 1 - 250 / Tri | 16017 | 3 - 400 | 250 | 340 | 0-444.3 | 444.3 | 1200 | 800 | 340 | Metal | — |
| Exclusive S 1 - 315 / Tri | 16018 | 3 - 400 | 315 | 430 | 0-553.6 | 553.6 | 1300 | 900 | 360 | Metal | — |
| Exclusive S 1 - 355 / Tri | 16019 | 3 - 400 | 355 | 485 | 0-623.9 | 623.9 | 1300 | 900 | 360 | Metal | — |
| Exclusive S 1 - 400 / Tri | 16020 | 3 - 400 | 400 | 544 | 0-703 | 703 | 1300 | 900 | 360 | Metal | — |
Exclusive S 2
| KOD | V- | kW | Hp | Aralık (A) | Max (A) | D | E | G | Malzeme | KG | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Exclusive S 2 - 7.5 / Tri | 16201 | 3 - 400 | 7.5 | 10 | 0-15.8 | 15.8 | 600 | 400 | 200 | Metal | — |
| Exclusive S 2 - 11 / Tri | 16202 | 3 - 400 | 11 | 15 | 0-25 | 25 | 600 | 400 | 200 | Metal | — |
| Exclusive S 2 - 15 / Tri | 16203 | 3 - 400 | 15 | 20 | 0-31.9 | 31.9 | 600 | 400 | 200 | Metal | — |
| Exclusive S 2 - 18.5 / Tri | 16204 | 3 - 400 | 18.5 | 25 | 0-37.1 | 37.1 | 600 | 400 | 200 | Metal | — |
| Exclusive S 2 - 22 / Tri | 16205 | 3 - 400 | 22 | 30 | 0-42.7 | 42.7 | 700 | 500 | 260 | Metal | — |
| Exclusive S 2 - 30 / Tri | 16206 | 3 - 400 | 30 | 40 | 0-57.6 | 57.6 | 700 | 500 | 260 | Metal | — |
| Exclusive S 2 - 37 / Tri | 16207 | 3 - 400 | 37 | 50 | 0-70.2 | 70.2 | 800 | 600 | 290 | Metal | — |
| Exclusive S 2 - 45 / Tri | 16208 | 3 - 400 | 45 | 60 | 0-83.5 | 83.5 | 1000 | 700 | 320 | Metal | — |
| Exclusive S 2 - 55 / Tri | 16209 | 3 - 400 | 55 | 75 | 0-100.9 | 100.9 | 1000 | 700 | 320 | Metal | — |
| Exclusive S 2 - 75 / Tri | 16210 | 3 - 400 | 75 | 100 | 0-140.7 | 140.7 | 1200 | 800 | 340 | Metal | — |
| Exclusive S 2 - 90 / Tri | 16211 | 3 - 400 | 90 | 125 | 0-165.1 | 165.1 | 1400 | 800 | 340 | Metal | — |
| Exclusive S 2 - 110 / Tri | 16212 | 3 - 400 | 110 | 150 | 0-201.9 | 201.9 | 1400 | 800 | 340 | Metal | — |
| Exclusive S 2 - 132 / Tri | 16213 | 3 - 400 | 132 | 180 | 0-242.2 | 242.2 | 1800 | 950 | 360 | Metal | — |
| Exclusive S 2 - 160 / Tri | 16214 | 3 - 400 | 160 | 220 | 0-290.6 | 290.6 | 1800 | 950 | 360 | Metal | — |
| Exclusive S 2 - 185 / Tri | 16215 | 3 - 400 | 185 | 250 | 0-332.4 | 332.4 | 2000 | 1000 | 420 | Metal | — |
| Exclusive S 2 - 200 / Tri | 16216 | 3 - 400 | 200 | 270 | 0-355.4 | 355.4 | 2000 | 1000 | 420 | Metal | — |
| Exclusive S 2 - 250 / Tri | 16217 | 3 - 400 | 250 | 340 | 0-444.3 | 444.3 | 2000 | 1000 | 420 | Metal | — |
| Exclusive S 2 - 315 / Tri | 16218 | 3 - 400 | 315 | 430 | 0-553.6 | 553.6 | 2100 | 1600 | 500 | Metal | — |
| Exclusive S 2 - 355 / Tri | 16219 | 3 - 400 | 355 | 485 | 0-623.9 | 623.9 | 2100 | 1600 | 500 | Metal | — |
| Exclusive S 2 - 400 / Tri | 16220 | 3 - 400 | 400 | 544 | 0-703 | 703 | 2100 | 1600 | 500 | Metal | — |
Exclusive S 3
| KOD | V- | kW | Hp | Aralık (A) | Max (A) | D | E | G | Malzeme | KG | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Exclusive S 3 - 7.5 / Tri | 16301 | 3 - 400 | 7.5 | 10 | 0-15.8 | 15.8 | 600 | 500 | 260 | Metal | — |
| Exclusive S 3 - 11 / Tri | 16302 | 3 - 400 | 11 | 15 | 0-25 | 25 | 600 | 500 | 260 | Metal | — |
| Exclusive S 3 - 15 / Tri | 16303 | 3 - 400 | 15 | 20 | 0-31.9 | 31.9 | 600 | 600 | 290 | Metal | — |
| Exclusive S 3 - 18.5 / Tri | 16304 | 3 - 400 | 18.5 | 25 | 0-37.1 | 37.1 | 600 | 700 | 320 | Metal | — |
| Exclusive S 3 - 22 / Tri | 16305 | 3 - 400 | 22 | 30 | 0-42.7 | 42.7 | 700 | 700 | 320 | Metal | — |
| Exclusive S 3 - 30 / Tri | 16306 | 3 - 400 | 30 | 40 | 0-57.6 | 57.6 | 700 | 800 | 340 | Metal | — |
| Exclusive S 3 - 37 / Tri | 16307 | 3 - 400 | 37 | 50 | 0-70.2 | 70.2 | 800 | 800 | 340 | Metal | — |
| Exclusive S 3 - 45 / Tri | 16308 | 3 - 400 | 45 | 60 | 0-83.5 | 83.5 | 1000 | 800 | 340 | Metal | — |
| Exclusive S 3 - 55 / Tri | 16309 | 3 - 400 | 55 | 75 | 0-100.9 | 100.9 | 1000 | 950 | 360 | Metal | — |
| Exclusive S 3 - 75 / Tri | 16310 | 3 - 400 | 75 | 100 | 0-140.7 | 140.7 | 1200 | 950 | 360 | Metal | — |
| Exclusive S 3 - 90 / Tri | 16311 | 3 - 400 | 90 | 125 | 0-165.1 | 165.1 | 1400 | 1200 | 420 | Metal | — |
| Exclusive S 3 - 110 / Tri | 16312 | 3 - 400 | 110 | 150 | 0-201.9 | 201.9 | 1400 | 1200 | 420 | Metal | — |
| Exclusive S 3 - 132 / Tri | 16313 | 3 - 400 | 132 | 180 | 0-242.2 | 242.2 | 1800 | 1200 | 420 | Metal | — |
| Exclusive S 3 - 160 / Tri | 16314 | 3 - 400 | 160 | 220 | 0-290.6 | 290.6 | 1800 | 1600 | 500 | Metal | — |
| Exclusive S 3 - 185 / Tri | 16315 | 3 - 400 | 185 | 250 | 0-332.4 | 332.4 | 2000 | 1600 | 500 | Metal | — |
| Exclusive S 3 - 200 / Tri | 16316 | 3 - 400 | 200 | 270 | 0-355.4 | 355.4 | 2000 | 1600 | 500 | Metal | — |
| Exclusive S 3 - 250 / Tri | 16317 | 3 - 400 | 250 | 340 | 0-444.3 | 444.3 | 2000 | 1600 | 500 | Metal | — |
| Exclusive S 3 - 315 / Tri | 16318 | 3 - 400 | 315 | 430 | 0-553.6 | 553.6 | 2100 | 1600 | 550 | Metal | — |
| Exclusive S 3 - 355 / Tri | 16319 | 3 - 400 | 355 | 485 | 0-623.9 | 623.9 | 2100 | 1600 | 550 | Metal | — |
| Exclusive S 3 - 400 / Tri | 16320 | 3 - 400 | 400 | 544 | 0-703 | 703 | 2100 | 1600 | 550 | Metal | — |
Exclusive S 4
| KOD | V- | kW | Hp | Aralık (A) | Max (A) | D | E | G | Malzeme | KG | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Exclusive S 4 - 7.5 / Tri | 16401 | 3 - 400 | 7.5 | 10 | 0-15.8 | 15.8 | 800 | 600 | 290 | Metal | — |
| Exclusive S 4 - 11 / Tri | 16402 | 3 - 400 | 11 | 15 | 0-25 | 25 | 800 | 600 | 290 | Metal | — |
| Exclusive S 4 - 15 / Tri | 16403 | 3 - 400 | 15 | 20 | 0-31.9 | 31.9 | 800 | 600 | 290 | Metal | — |
| Exclusive S 4 - 18.5 / Tri | 16404 | 3 - 400 | 18.5 | 25 | 0-37.1 | 37.1 | 1000 | 700 | 320 | Metal | — |
| Exclusive S 4 - 22 / Tri | 16405 | 3 - 400 | 22 | 30 | 0-42.7 | 42.7 | 1000 | 700 | 320 | Metal | — |
| Exclusive S 4 - 30 / Tri | 16406 | 3 - 400 | 30 | 40 | 0-57.6 | 57.6 | 1200 | 800 | 340 | Metal | — |
| Exclusive S 4 - 37 / Tri | 16407 | 3 - 400 | 37 | 50 | 0-70.2 | 70.2 | 1400 | 800 | 340 | Metal | — |
| Exclusive S 4 - 45 / Tri | 16408 | 3 - 400 | 45 | 60 | 0-83.5 | 83.5 | 1400 | 800 | 340 | Metal | — |
| Exclusive S 4 - 55 / Tri | 16409 | 3 - 400 | 55 | 75 | 0-100.9 | 100.9 | 1800 | 950 | 360 | Metal | — |
| Exclusive S 4 - 75 / Tri | 16410 | 3 - 400 | 75 | 100 | 0-140.7 | 140.7 | 1800 | 950 | 360 | Metal | — |
| Exclusive S 4 - 90 / Tri | 16411 | 3 - 400 | 90 | 125 | 0-165.1 | 165.1 | 2000 | 1600 | 500 | Metal | — |
| Exclusive S 4 - 110 / Tri | 16412 | 3 - 400 | 110 | 150 | 0-201.9 | 201.9 | 2000 | 1600 | 500 | Metal | — |
| Exclusive S 4 - 132 / Tri | 16413 | 3 - 400 | 132 | 180 | 0-242.2 | 242.2 | 2000 | 1600 | 500 | Metal | — |
| Exclusive S 4 - 160 / Tri | 16414 | 3 - 400 | 160 | 220 | 0-290.6 | 290.6 | 2200 | 1600 | 550 | Metal | — |
| Exclusive S 4 - 185 / Tri | 16415 | 3 - 400 | 185 | 250 | 0-332.4 | 332.4 | 2200 | 1600 | 550 | Metal | — |
| Exclusive S 4 - 200 / Tri | 16416 | 3 - 400 | 200 | 270 | 0-355.4 | 355.4 | 2200 | 1600 | 550 | Metal | — |
| Exclusive S 4 - 250 / Tri | 16417 | 3 - 400 | 250 | 340 | 0-444.3 | 444.3 | 2200 | 1600 | 550 | Metal | — |
| Exclusive S 4 - 315 / Tri | 16418 | 3 - 400 | 315 | 430 | 0-553.6 | 553.6 | 2400 | 1800 | 600 | Metal | — |
| Exclusive S 4 - 355 / Tri | 16419 | 3 - 400 | 355 | 485 | 0-623.9 | 623.9 | 2400 | 1800 | 600 | Metal | — |
| Exclusive S 4 - 400 / Tri | 16420 | 3 - 400 | 400 | 544 | 0-703 | 703 | 2400 | 1800 | 600 | Metal | — |
