Direct SmartHexa
Direct SmartHexa - RH
Tap to inspect in full screen
Overview
SmartHexa RH delivers high efficiency with its advanced electronic control system while prioritizing domestic hot water (DHW) production. The unit continuously monitors system parameters to ensure reliable and optimal performance. With its stainless steel heat exchanger and piping, it provides long-lasting durability and operates efficiently with radiator heating systems. Thanks to its motorized control valve and intelligent control algorithms, SmartHexa RH ensures stable and precise hot water comfort. Optional outdoor compensation control enhances energy efficiency by adapting to changing ambient conditions. Integrated smart features such as PC connectivity, return temperature control, anti-legionella function, and keep warm mode provide enhanced performance and user comfort. All operational data can be transmitted to the BLES system for remote monitoring and control.
Technical Features
- Fully electronic control with PC connectivity via GSM or Ethernet for easy setup and commissioning
- Fast and precise DHW control with calibrated sensors
- Return temperature control for district heating with a high-efficiency heat exchanger
- Smart anti-legionella function for safe domestic hot water
- Pump and valve exercise mode to prevent sticking and ensure reliable operation
- Compatible with radiator heating systems, ensuring reliable performance at higher temperature levels
- Proportional motorized control valve for precise temperature management
Technical Data
Product Specifications
| Specification | Value |
|---|---|
| Suitable for district heating | YES |
| Suitable for heat pump | NO |
| Suitable for heating | YES |
| Suitable for cooling | NO |
| Suitable for hot tap water | YES |
| Suitable for working with circulation pump | YES |
| High efficiency pump | NO |
| DHW Heat Exchanger | YES |
| Material of heat exchanger | Stainless steel with copper soldered |
| Full sealed heat exchanger | YES |
| Suitable for using and fitting with heat meter | YES |
| Suitable for using and fitting with cold water meter | YES |
| Primary supply temperature | 0 - 110°C |
| Primary pressure difference | 20-60 kPa |
| Continuous hot water capacity | 15 l/m - 17 l/m at 65°C |
| DHW capacity | 37 kW - 46 kW |
| Max. Heating capacity | - |
| Inlet / Outlet connections for Heating, cold water, hot water and primary supply | 3/4" Female connections |
| Hot water priority | YES |
| Differential Pressure Balancing Valve included | YES |
| Keep warm function | YES |
| Strainer for primary line | YES |
| Zone valve control for heating side | NO |
| Height | 530 mm |
| Width | 500 mm |
| Depth | 170 mm |
